FLEXIBLE ELECTRIC CABLES PVC INSULATED, UNDER MEDIUM LIGHT PVC SHEATH
Applications:
In private houses, kitchens and offices; For connecting light portable appliances subject to light mechanical stress. Not suitable for heating or
Cooking appliances, outdoors or in factories or farms or for portable non-household appliances.
Conductor:
Flexible plain annealed copper wires class 5 to IEC EN 60228.
Insulation:
Polyvinylchloride type TI2
Sheath:
Polyvinylchloride type TM2
Marking:
Continuous marking on the sheath accroding to the customer’s requirements
Operating temperature:
+5º C ÷ +60º C on the conductor
Specfication
|
Area Section |
Max diameter of wires in conductor |
Insulation thickness medio average |
Sheat thickness medio average |
Nominal outer diameter |
Max conductor resistance at 20°C |
Indicative cable weight |
|
2×0.5mm2 |
0.20 |
0.5 |
0.6 |
3.1×5.0 |
39.0 |
30 |
|
2×0.75mm |
0.20 |
0.5 |
0.6 |
3.3×5.4 |
26.0 |
35 |
